Loading spritesheets

The Graphic Entity Module can cut and handle spritesheets. There are two ways of doing that.

Using the SpriteSheetSplitter

This is the easiest way to create a set of sprites from a spritesheet. This solution is good for prototyping but it is performance costly.

For this example, we will use this spritesheet (taken from our free to use assets repository):

• 12 images
• 4 images per row
• Each of them is 128px wide and high
• We want to use all the images starting from the top left corner, so the OrigRow and OrigCol must be set to 0

String[] seaweedSprites = graphicEntityModule.createSpriteSheetSplitter()
    .setSourceImage("spritesheet.png")
    .setImageCount(12)
    .setWidth(128)
    .setHeight(128)
    .setOrigRow(0)
    .setOrigCol(0)
    .setImagesPerRow(4)
    .setName("seaweed")
    .split();

//Creating an animation from the splitted spritesheet
graphicEntityModule.createSpriteAnimation()
    .setImages(seaweedSprites)
    .setX(50)
    .setY(50)
    .setLoop(true);

//Or a sprite from the 1st image of the spritesheet
graphicEntityModule.createSprite()
    .setImage(seaweedSprites[0])
    .setX(250)
    .setY(250);

It should look like this :

Using JSON sprites resources as assets

This method is slightly longer to setup but is more performant. In addition, this allows you to use spritesheets that are not necessarily in a grid layout.

First, you will need to generate a JSON Hash file. We suggest you use Leshy SpriteSheet Tool.

Your file should look like this.

{
   "frames":{
      "seaweed1":{
         "frame":{
            "x":0,
            "y":0,
            "w":128,
            "h":128
         },
         "rotated":false,
         "trimmed":false,
         "spriteSourceSize":{
            "x":0,
            "y":0,
            "w":128,
            "h":128
         },
         "sourceSize":{
            "w":128,
            "h":128
         }
      },
      "seaweed2":{
         "frame":{
            "x":128,
            "y":0,
            "w":128,
            "h":128
         },
         "rotated":false,
         "trimmed":false,
         "spriteSourceSize":{
            "x":0,
            "y":0,
            "w":128,
            "h":128
         },
         "sourceSize":{
            "w":128,
            "h":128
         }
      },
      ⋮
   }
}

Place this file in the assets folder, you can now use each image with their name as if they were splitted in different files.
